| Place of Origin: | CHINA |
|---|---|
| Brand Name: | JIAXIN |
| Certification: | CCC VDE CE CB |
| Model Number: | H03VV-F、RVV |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | Steel Wooden Drum |
| Delivery Time: | 7-15 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, T/T |
| Supply Ability: | 100KM/WEEK |
| Model Name: | H03VV-F / 60227 IEC 52(RVV) | Size: | 0.5~0.75 Mm2 |
|---|---|---|---|
| Rated Temperature: | 70℃ | Standard: | VED/CE/CCC/CB |
| Voltage Rate: | 300/500 V | Application: | Construction |
| Highlight: | RVVP RVV Industrial Flexible Cable,H03VV-F Industrial Flexible Cable,RVVP RVV h03vvf cable |
||
2*0.75MM RVVP RVV IIndustrial Flexible Cable H03VV-F For Construction
300/500 V 3 round pin 5amp plug EU 2pin plug power cord 2 pin H03VV-F
House Wire 2*0.75MM 1MM 1.5MM 2.5MM 4MM 6MM Flexible Power Cable RVVP RVV Cable H03VV-F
The cables are intended for the connection of domestic appliance to the fixed supply.
▼ Constraction:
1. Core Conductor: Stranded bare copper
2. Popular sizes: 2~4 core × 0.5~0.75mm²
3. Insulation&Jacket : PVC
4. Other specs:
a) Temperature rating: -15C up to +70℃
b). Fire performance: EN 50525-2-11:2011 ; IEC 60227
c). Approval: VDE CE CB CCC
d). Voltage suitable: 300/500V
3. Insulation is anti-oxidation and anti-aging, using native environmentally friendly polyvinyl chloride, not easy to deform and wear.
▼ Standards&Certificates:
EN 50525-2-11:2011 ; IEC 60227
▼ Technical parameters:
| Cross section of conductor(mm²) | Conductor structure(mm) | Insulation thickness(mm) | Sheath thickness(mm) | Approx. cable diameter(mm) | Max resistance of conductor at 20℃ (Ω/km) |
| 2×0.75 | 24 | 0.6 | 0.8 | 6.3 | 26.0 |
| 2×0.75 | 24 | 0.6 | 0.8 | 4.0×6.4 | 26.0 |
| 2×1 | 32 | 0.6 | 0.8 | 6.7 | 19.5 |
| 2×1 | 32 | 0.6 | 0.8 | 4.2×6.8 | 19.5 |
| 2×1.5 | 30 | 0.7 | 0.8 | 7.7 | 13.3 |
| 2×2.5 | 49 | 0.8 | 1.0 | 9.3 | 7.98 |
Production Process
P1: Wire Cutting
P2: Terminal Crimp
P3: Terminal Crimp
P4: Peeling
P5: Tin Plating
P6: Assembly
P7: Twist
P8: Inspection
P9: Test
